Concrete Pumps

Electric Concrete Pump Specs

Static Electric Pump	SP 750 E	SP 750 E	BSA 1408 E	BSA 2109 E
Output (rod side)			79 m3/hr	85 m3/hr
Output (piston side)			53 m3/hr	51 m3/hr
Concrete Output Max	38 m3/hr	54 m3/hr
Delivery Pressure (rod side)			71 bar	91 bar
Delivery Pressure (piston side)			106 bar	152 bar
Pressure on concrete max. bar	76 bar	76 bar
Strokes (rod side) per min			30	21
Strokes (piston side) per min			20	13
Stroke rate max.	35 1/min	35 1/min
Concrete valve	L-ROCK	L-ROCK
Engine power	55 kW		110 kW	160 kW
Frequency	50 Hz
Delivery Cylinder Diameter / Stroke Length	150/1000 mm	180/1000 mm	200/1400 mm	200/2100 mm
Pressure Connection			125 mm	150 mm
Length x Width x Height			5745 x 2021 x 2146 mm	6825 x 2170 x 2475 mm
Weight	3000 kg	3400 kg	4900 kg	6600 kg
Trailer Type			F8	F8
Pump Kit	P1015	P1018
Hydraulic system	Open system, dual-circuit hydraulics
Hydraulic tank	265 I
Efficiency class	IE 3
